Image 3
SEM of partial bainitic transformation, formed after transformation at 250°C for 10 h (a) with NiAl. The arrow indicates the intragranular nucleation of bainite from the NiAl precipitates. (b) Without NiAl, nucleation is from the austenite grain boundaries.
Image 3
STEM bright field images of the transformed alloy. Microstructure of an interrupted bainitic transformation at 250°C for (a) 10 h. (b) 50 h, (b) shows the the nucleation of bainite from the NiAl precipitates where the bainite is seen to grow into many directions.
Image 1
EBSD orientation image, sample transformed isothermally at 250°C for 150 h followed by cooling to ambient temperature. Bainite nucleated from NiAl promotes a more chaotic and finer bainite structure.
Image 2
EBSD orientation image, sample transformed isothermally at 250°C for 150 h followed by cooling to ambient temperature. Grain boundary nucleated bainite.
Image 3
Pole figures from a parent austenite grain, (a and b) {100}γ pole figure, (c and d) corresponding {100}α pole figure, more variants within the austenite grain (c).
Explanation for Video 1
Explanation for Video 2
